PG Drives Technology S70A User Manual

S-DRIVE - SPECIFICATIONS PG DRIVES TECHNOLOGY
SK76745/10
92
1 Electrical Specifications
Model
S45A
S70A
S90A
S120A
S140A
S200A
Supply Voltage
24Vdc
24Vdc
24Vdc
Operating Voltage
16 – 30Vdc
16 – 30Vdc
16 – 45Vdc
Peak Voltage
35Vdc
35Vdc
45Vdc
Reverse Battery Voltage
40Vdc
40Vdc
60Vdc
Output Current
45A
70A
90A
120A
140A
200A
PWM Frequency
20kHz + / - 1%
Power Connection
6.35mm (0.25”) Faston spade
D51059 (Battery)
D51070 (Motor)
M6 screw
terminals
Brake Connection
2-way Molex Mini-fit Jr
Charger/ Programmer
Connection
4-way Molex Mini-fit Jr
Tiller Connection
14-way Molex Mini-fit Jr
Brake Voltage
24Vdc
Brake Current
1.25max continuous
Status Output
Programmable 0-12V, 50mA sink
Battery Charging Current
9Arms max-Via charger port
5Arms max- Via tiller socket
Inhibit Input
Programmable polarity
Moisture Resistance
Electronics to IPX5 / Connections to IPX4 with cable cover
Operating Temperature
-25°C to +50°C
Storage Temperature
-40°C to +65°C
Safety
Multiple hardware & software strategy designed to ISO7176/14:2008
EMC Susceptibility
Tested at 30V/m to EN12184 and ANSI/RESNA
EMC Emissions
To EN55022 Class B
ESD
IEC 801 part 2
