5.18
BODY / STEERING / SUSPENSION
9923412 - 2012 Sportsman 400/500 and EFI Tractor Service Manual
© Copyright 2011 Polaris Sales Inc.
500 EFI TRACTOR STEERING POST AND LOCK
Steering Assembly Exploded View
The 500 EFI Tractor is equipped with a steering locking mechanism to prevent theft or unauthorized use. Refer to the
standard torque specifications chart in Chapter 1 whenever servicing the steering lock components.
Lock System / Description
A. Lock Collar
B. Lock Set
C. Bolt, Lock Set
D. Bolt(s), Lock Collar
E. Nut(s), Lock Collar
A
B
C
D
E
