Polaris RZR 570 2013 Service Manual

6.2
9926813 R04 - 2013-2016 RZR 570 Service Manual
© Copyright Polaris Industries Inc.
GENERAL INFORMATION
TORQUE SPECIFICATIONS
ITEM
TORQUE VALUE
Bearing Carrier Nuts
(Rear)
40 ft-lb (54 Nm)
Bearing Retaining Plate
Screws
8 ft-lbs (11 Nm)
Bell Crank Nut
15 ft-lbs (20 Nm)
Brake Caliper Mounting
Bolts (Rear)
44 ft-lbs (60 Nm)
Clutch Cover (Outer)
Screws
100 in-lbs (12 Nm)
Differential Cover
Screws (INTL)
21 ft-lb (28 Nm)
Drive Clutch Retaining
Bolts
47 ft-lbs (64 Nm)
Driven Clutch Retaining
Bolts
36 ft-lbs (49 Nm)
Engine to Transmission
Coupler Bolts
55 ft-lbs (75 Nm)
Fill / Drain Plugs 12 ft-lbs (16 Nm)
Gear Sector Cover
11 ft-lbs (15 Nm)
Park Brake Disc
Mounting Bolt (INTL)
8 ft-lbs (11 Nm)
Park Flange Screws 8 ft-lbs (11 Nm)
PVT Inner Cover Bolts
12 ft-lbs (16 Nm)
Rear Transmission
Isolator Mount Bolt
40 ft-lbs (54 Nm)
Snorkel Tube
Refer to “Snorkel Gear
Backlash Procedure”
Snorkel Tube Locking
Screw
8 ft-lbs (11 Nm)
Starter Mounting Bolts 7 ft-lb (10 Nm)
Support and Shift Cable
Bracket Bolts
17 ft-lbs (23 Nm)
ITEM
TORQUE VALUE
Transmission Shift Fork
Screws
8 ft-lb (11 Nm)
Transmission Case
Bolts
17 ft-lbs (23 Nm)
Speed Sensor Screw 8ft-lbs (11 Nm)
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
PA-50231 Snorkel Tool
2871698 (Part of 2871702
Kit)
Rear Output Seal
Driver
2871699 (Part of 2871702
Kit)
Rear Driveshaft Seal
Guide
2871282
Bearing Seal Driver
(50 mm)
PU-50566
Transmission Nut
Socket
PU-50658
Clutch Center
Distance Tool
Bosch Automotive Service Solutions – 1-800-328-6657
or http://polaris.service-solutions.com/
LUBRICATION
FLUID CAPACITY
Recommended Transmission Lubricant:
AGL (PN 2878068) (Quart)
Capacity (Standard): 44 oz. (1300 ml)
Capacity LE / INTL: 41 oz. (1200 ml)
TRANSMISSION
