Polaris RZR 570 2013 Service Manual

6.52
9926813 R04 - 2013-2016 RZR 570 Service Manual
© Copyright Polaris Industries Inc.
Exploded View (Int’l), Continued
1.
Fill Plug
36.
Bearing, Needle Cage
70.
Fork, Shift
2.
Drain Plug, Magnetic
37.
Bearing, Ball
71.
Sprocket, 48T, 6-Face
4.
Screw, M8 x 1.25 x 30
38.
Bearing, Ball
72.
Gear, Low 67T
5.
Screw, M6 x 1 x 20
39.
Bearing, Ball
73.
Engagement Dog, 6-Face
6.
Screw, M8 x 50
40.
Spring, Compression
74.
Gear, 53T
7.
Screw, M6 x 1 x 40
41.
Spring, Compression
75.
Gear, 46T
8.
Screw, M6 x 1 x 18
42.
Spring, Torsion
76.
Gear, Snorkel 13T
9.
Screw, M6 x 1 x 16
43.
Spring, Compression
77.
Shaft, Shift
10.
Nut, NyLoc, M8 x 1.25
44.
Spring, Compression,
Detent
78.
Weldment, Rear Mount
Bracket
11.
Washer, Cup
45.
Spring, Washer
80.
Retainer, Fork
12. Washer 46.
Tube, Snorkel
81.
Bracket, Rear Mount
13. Washer 47.
Cover, Sector Gears
82.
Cover, Bearing, Center
Drive
14.
Washer 48.
Case, LH
83.
Spacer
15. Washer 49.
Case, RH
84.
Chain, Silent
16.
Pin, Dowel
50.
Drum, Shift
85. Solenoid
17.
Pin, Spring
51.
Gear, Sector 16T
86.
Switch, Rotary, 2-Pin
18.
Retaining Ring, External
52.
Gear, Sector 31T
87.
O-Ring
19.
Snap Ring
53.
Pawl, Detent
88.
O-Ring
20.
Retaining Ring, External
54.
Star, Detent
89.
O-Ring
21.
Retaining Ring, External
55.
Plate, Park, 12-Face
90.
Seal, Triple Lip
22.
Retaining Ring, Internal
56.
Shaft, Idler 29T
91.
Seal, Triple Lip
23.
Retaining Ring, External
57.
Shaft, Reverse 29T
92.
Seal, Dual Lip
24.
Retaining Ring, External
58.
Shaft, Front Output
93.
Seal, Triple Lip
25.
Retaining Ring, External
59.
Shaft, Input Helical
95.
Sensor, Speed
26.
Retaining Ring, External
60.
Shaft, Pinion, 11T
98.
Bracket, Wire Harness
27.
Washer, Thrust
61.
Disc, Brake
99.
Plug, Expansion
28.
Washer, Thrust
62. Bellcrank 100.
Side Gear, Male, 39T
29. Shim 63.
Collar, Shift
101.
Bearing, Plain
30. Shim 64.
Rail, Shift Shaft
102.
Side Gear, Female, 39T
31.
Bearing, Needle Cage
65.
Tube, Vent, 1/4 in.
103. Diff Cover
32.
Bearing, Ball
66.
Fork, Pivot Shaft
104. Planet Gear
33.
Bearing, Ball
67.
Dog, Engagement
105.
Screw, M8 x 1.25 x 25
34.
Bearing, Ball
68.
Shift Dog, Park
106.
Ring Gear, 53T
35.
Bearing, Ball
69.
Gear, 44T
108.
Bearing, Plain
TRANSMISSION
