11
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
11.13
SEAT ASSEMBLY
TORQUE REFERENCE
q
Seat Slider RH
y
Tilt Assembly Bracket
w
Seat Slider LH
u
Tilt Assembly Bracket Fastener
15 ft-lbs (20 Nm)
e
Seat Hinge Bushing (lower)
i
Seat Tilt Receiver
r
Seat Hinge Bushing (upper)
o
Latch Hook
t
Seat Hinge Nut
7 ft-lbs (10 Nm)
a
Latch Hook Fastener
9 ft-lbs (12 Nm)
BODY / FRAME
