9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
11.25
ROCKER PANELS, CONSOLE, AND
FLOOR
ROCKER PANEL REMOVAL
1. Remove front fender flare. See Fender Flare
Removal page 11.23.
2. Remove rear fender and fender flare. See Rear
Fender / Fender Flare Removal page 11.24.
3. Remove five fasteners
q
and remove rocker panel.
CONSOLE AND LOWER FLOOR REMOVAL
1. Remove seats and rocker panels.
2. Remove top half of shift knob
w
.
3. Remove one fastener
e
and remove lower shift knob
half
r
.
4. Disconnect 12V outlet connections from under the
center storage console.
5. Remove nine fasteners
t
from either side of the
console.
6. Remove one fastener
y
from either side of the
console under the dash.
BODY / FRAME
