Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide Confidential / Released 10 / 59
2 General Overview
Quectel supplies Smart EVB G2 for designers to develop applications based on Quectel
SG30/SG36/SC60 modules. This EVB can test basic functionalities of these modules.
Key Features 2.1.
The following table describes the detailed features of Smart EVB G2.
Table 1: Key Features
DC power supply: 4.75V~6.0V (typical: 5.0V)
VBAT: 3.5V~4.4V (typical: 3.8V)
Two 5-inch 1280 × 720 HD resolution liquid crystal displays
4-lane MIPI DSI interface for each LCD module
Two 5-point capacitive touch panels
Support three cameras:
Rear camera supports 16M pixels with 4-lane CSI interface
Front camera supports 8M pixels with 2-lane CSI interface
Depth camera supports 2M pixels with 1-lane CSI interface
USB type-C interface
Compliant with USB 3.0 and 2.0 specifications, with transmission rates up
to 5Gbps on USB 3.0 and 480Mbps on USB 2.0.
Support USB OTG
Used for AT command communication, data transmission, software
debugging and firmware upgrade
Analog Input:
3 groups of analog microphone inputs, integrating internal bias voltage.
One for headset, one for ECM-type microphone and one for MEMS-type
microphone.
Analog Output:
3 groups of analog audio outputs, including:
One stereo headset output
One mono earphone differential output
