Quectel Smart EVB G2 User Manual

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide Confidential / Released 54 / 59
Figure 50: “adb shell” Command
1. If customers want to use HyperTerminal for testing, then Qualcomm HS-USB Modem 9091 can be
used.
2. Please note that the USB port numbers may be different among different modules.
5.2.2. Communication via UART Interface
1. Run the driver disk on PC to install the USB-to-RS232 driver.
2. Connect the UART interface (main UART or debug UART) to the PC with USB-to-RS232 converter
cable and then power on the module according to the procedures mentioned in Chapter 5.1. After
that, the USB serial port number can be viewed through the PC Device Manager, shown as the
following figure.
Figure 51: USB Serial Port
NOTES
Quectel
Confidential
