Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide Confidential / Released 49 / 59
Vibrator 4.14.
Smart EVB G2 provides an ERM-type vibrator for customers to test the motor driver interface of Smart
modules. The following figures show a reference circuit design and the vibrator on the board.
HAP_N
33pF
Module
VIB+
Motor
VIB-
C2
33pF
C1
HAP_P
Figure 44: Reference Circuit Design for Vibrator
ERM-Type
HAP_P
HAP_N
Figure 45: ERM-Type Vibrator
