RC3000E (P100R001) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
3
1.4 Card types
Uplink subcards
Table 1-1 lists the types of the uplink subcard.
Table 1-1 Types of the uplink subcard
Model
Name
Description
RC3000E-UP-8E1
Unlink E1 interface card

8 E1 channels

75 Ω unbalanced interface
RC3000E-UP-8E1-BL
Unlink E1 interface card

8 E1 channels

120 Ω balanced interface
RC3000E-UP-4E1
Unlink E1 interface card

4 E1 channels

75 Ω unbalanced interface
RC3000E-UP-4E1-BL
Unlink E1 interface card

4 E1 channels

120 Ω balanced interface
RC3000E-UP-OPT-
FE2E1
Unlink PDH optical interface
card

Optical interface uplink

(6+2) E1 and 100 Mbit/s Ethernet
multiplexing
Interface cards
Table 1-2 lists the types of the interface card.
Table 1-2 Types of the interface card
Model
Name
Description
RC3000-SUB-DV35
V35 data interface card

Provide 1 channel.

The number of occupied timeslots can
be configured.
RC3000-SUB-DV24
V24 data interface card

Provide 4 channels.

The rate for each channel services can
be adjusted (64–128 kbit/s).
RC3000-SUB-D232
RS232 serial interface card

Provide 8 channels.

Hardware configurations cannot be
adjusted.
RC3000-SUB-D485
RS485 serial interface card

Provide 8 channels.

Hardware configurations cannot be
adjusted.
RC3000-SUB-DETH×2
Two-way Ethernet data interface card

Provide 2 channels.

The number of occupied timeslots can
be configured.
RC3000-SUB-DC64K
Codirectional 64K data interface card

Provide 4 channels.

Hardware configurations cannot be
adjusted.
RC3000-SUB-10FXS
FXS audio user interface card

Provide 10 channels.

Voice gains can be adjusted.
RC3000-SUB-10FSO
FXO audio user interface card

Provide 10 channels.

Voice gains can be adjusted.
