Raisecom
RC3000E (P100R001) Product Description
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
Grey background with
purple loop
The RC3000E, as a Tie line device, uses the E&M signalling type of Type V, as shown in
Figure 4-4.
Figure 4-4 E&M signaling type
4.6.4 Technical specifications
Dimensions: 70 mm (Width) × 167.5 mm (Depth) × 20 mm (Height)
4.7 RC3000-SUB-DETH×2
4.7.1 Appearance and functions
The RC3000-SUB-DTH×2 is the subcard for transmitting Ethernet services on the RC3000E.
Provide 2 100Based-T Ethernet electrical interfaces.
Two Ethernet channel are independent from each other and you can configure or check either of them
individually.
The number of channels occupied by the interface can be configured. The number of channels ranges from 0
to 31, that is, the bandwidth of the interface is N × 64 kbit/s (N: 0–31).
The MTU of the Ethernet interface is 1518 bytes.
