Raisecom RC3000E User Manual

Raisecom
RC3000E (P100R001) Product Description
4 Cards
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
26
Panel
Function
The 10FXS/10FXO is an auto interface card on the RC3000E.

It is embedded with feeding and ringing modules, and can be connected to a telephone or a Stored Program
Control (SPC) switch through the exterior line interface.

Provide 10 channels, the number of which depends on the hardware and cannot be changed.

Support polarity inversion.

Support high-impedance recording.

The RC3000E-SUB-10FXS/10FXO of B.10 or later (with the PCB version of B.3 or
later) supports high-impedance recording, namely, the FXO-R voice module and
recording.

In slot configuration mode, use the show version command to view the PCB
version.

The voice module of the FXS, FXO, and FXO-R can be customized instead of
being switched through software.
4.5.2 Slots
The RC3000-SUB-10FXS/10FXO can be inserted into slots 1–3.
4.5.3 Interfaces
RJ45
PIN
Channel
Signal
PORT 1
1–2
1
CHANN1A/CHANN1B
3–4
2
CHANN2A/CHANN2B
5–6
3
CHANN3A/CHANN3B
7–8
4
CHANN4A/CHANN4B
PORT 2
1–2
5
CHANN5A/CHANN5B
3–4
6
CHANN6A/CHANN6B
5–6
7
CHANN7A/CHANN7B
7–8
8
CHANN8A/CHANN8B
PORT 3
1–2
9
CHANN9A/CHANN9B
3–4
10
CHANN10A/CHANN10B
5–6
Reserved
–
7–8
Reserved
–
