Raisecom RC3000E User Manual

Raisecom
RC3000E (P100R001) Product Description
4 Cards
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
52
Table 4-28 PIN definitions of RJ45 interface in RC3000-SUB-D485 mode
Mode
PIN
V.24
RS232
RS422
RS485
1
GND
GND
GND
GND
2
NC
NC
NC
NC
3
NC
NC
NC
NC
4
RS485_A0
RS485_A1
RS485_A2
RS485_A3
5
RS485_B0
RS485_B1
RS485_B2
RS485_B3
6
NC
NC
NC
NC
7
NC
NC
NC
NC
8
GND
GND
GND
GND
NC in Table 4-25, Table 4-26, Table 4-27, and Table 4-28 refers to no connection.
4.14.6 LEDs
There are three LEDs on the RC3000-SUB-RS24.
Table 4-29 lists LEDs on the RC3000-SUB-RS24.
Table 4-29 LEDs on the RC3000-SUB-RS24
LED
Status
Description
1
Green
Subcard working status LED

Green: the subcard works in hardware configuration status.

Off: the subcard works in software configuration status.
2
Green
LED 2 and LED 3 are used together.

When the subcard works in hardware configuration status, they
indicate the type of the current subcard.

When the subcard works in software configuration status, they
indicate the working mode of the first RJ45 interface.
3
Green
Table 4-30 describes indications of LED 2 and LED 3.
