RC3000E (P100R001) Product Description
5 Networking and applications
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
55
5 Networking and applications
This chapter includes the following sections:

Typical applications of device

Application modes of RC3000E-UP-OPT-FE2E1
5.1 Typical applications of device
Figure 5-1 Typical applications of the RC3000E (1)
As shown in Figure 5-1, it is a typical point-to-point networking application of the RC3000E.
Both the two RC3000E devices can transmit voice and data services to realize point-to-point
transmission. The NView NNM system can manage the RC3000E devices comprehensively.
Figure 5-2 Typical applications of the RC3000E (2)
As shown in Figure 5-2, it is a typical chain cascading networking application of the
RC3000E. RC3000E 1, RC3000E 2, and RC3000E 3 can transmit voice and data services.
The NView NNM system can manage the RC3000E devices comprehensively.
