RC3000E (P100R001) Product Description
7 Appendix
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
64
Figure
PIN
Signal
Definition
Chanel
11
OUT5-
TX5
Channel 5
12
OUT5+
29
IN5+
RX5
30
IN5-
13
OUT6-
TX6
Channel 6
14
OUT6+
31
IN6+
RX6
32
IN6-
15
OUT7-
TX7
Channel 7
16
OUT7+
33
IN7+
RX7
34
IN7-
17
OUT8-
TX8
Channel 8
18
OUT8+
35
IN8+
RX8
36
IN8-

It is connected to the core of coaxial cables if marked plus (+); namely, the PIN is
welded with the core of the coaxial cable.

It is connected to the shielding layer of coaxial cables if marked hyphen (-);
namely, the PIN is welded with the shielding layer of the coaxial cable.

The wiring is also applicable to the CBL-E1-DB37F/16BNCM.
7.2.2 CBL-E1-DB37F/8RJ45
Figure
DB37F PIN
RJ45 PIN
Signal
Definition
Channel
DB37F
3
5
OUT1-
TX1
Channel 1
4
4
OUT1+
21
2
IN1+
RX1
22
1
IN1-
5
5
OUT2-
TX2
Channel 2
6
4
OUT2+
