Raisecom RC3000E User Manual

Raisecom
RC3000E (P100R001) Product Description
3 Technical specifications
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
14
Parameter
Description
Transparent transmission

Support IEEE 802.1d Spanning Tree transparent
transmission.

Support IEEE 802.1q VLAN packet transparent
transmission
Auto-MDI/MDIX
Supported
RS232 serial interface
Table 3-14 lists specifications of the RS232 serial interface.
Table 3-14 Specifications of the RS232 serial interface
Parameter
Description
Physical features
Comply with the interface standard in RS232 communication
protocol.
Interface type
RJ45 connector
Interface rate
≤ 19.2 kbit/s
The maximum length of the cable used for the RS232 interface was 15 m based on
RS232 standard.
RS485 serial interface
Table 3-15 lists specifications of the RS485 serial interface.
Table 3-15 Specifications of the RS485 serial interface
Parameter
Description
Physical features
Comply with the interface standard in RS485 communication
protocol.
Interface type
RJ45 connector
Interface rate
≤ 19.2 kbit/s
Codirectional 64K data interface
Table 3-16 lists specifications of the Codirectional 64K data interface.
