RC3000E (P100R001) Product Description
4 Cards
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
27
In actual application, you can define that voice signal A is connected to the Tip line
while voice signal B is connected to the Ring line
4.5.4 LEDs
Table 4-3 lists the LEDs on the RC3000E-SUB-10FXS/10FXO.
Table 4-3 LEDs on the RC3000E-SUB-10FXS/10FXO
No.
Description
Status
Description
1
FXS
Green

Green: the card works in FXS mode.

Off: the card works in FXO or FXO-R mode or
fails.
2
FXO
Green

Green: the card works in FXO or FXO-R mode.

Off: the card works in FXS mode or fails.
4.5.5 Technical specifications
Dimensions: 70 mm (Width) × 167.5 mm (Depth) × 20 mm (Height)
Maximum power consumption:

RC3000-SUB-10FXS: < 10 W

RC3000-SUB-10FXO < 2.5 W

RC3000-SUB-10FXO-R < 2.5 W
4.5.6 Application
The RC3000E-SUB-10FXS/10FXO of B.10 or later (with the PCB version of B.3 or later)
supports high-impedance recording, with the networking and function shown in Figure 4-2.

The FXO-R interface on the RC3000E-SUB-10FXO is connected to the telephone line
of the recorded telephone in physically parallel mode. It extracts voice services when the
recorded telephone is being answered.

Timeslots of the FXO-R interface on the RC3000E-SUB-10FXO are cross-connected to
those of the FXS interface on the RC3000E-SUB-10FXS. The FXO-R interface extracts
voice services of the recorded telephone when the FXS interface is connected to the
recorded telephone or the monitor telephone.

The Recorder records voice or rings according to the ring current sent by the FXS
module. It starts recording as long as Telephone B receives or originates a call and has
established a conversation (when to record depends on configurations of the Recorder).
