Raisecom RC3000E User Manual

Raisecom
RC3000E (P100R001) Product Description
7 Appendix
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
66
7.2.3 CBL-E1-DB9M/4BNCF
Figure
PIN
Signal
Definition
Channel
DB9M
1
IN1+
RX1
Channel 1
6
IN1-
2
OUT1+
TX1
7
OUT1-
3
IN2+
RX2
Channel 2
8
IN2-
4
OUT2+
TX2
9
OUT2-

It is connected to the core of coaxial cables if marked plus (+); namely, the PIN is
welded with the core of the coaxial cable.

It is connected to the shielding layer of coaxial cables if marked hyphen (-);
namely, the PIN is welded with the shielding layer of the coaxial cable.

The wiring is also applicable to the CBL-E1-DB9M/4BNCM.
7.2.4 CBL-E1-DB9M/2RJ45
Figure
DB9M PIN
RJ45 PIN
Signal
Definition
Channel
DB9M
RJ45
7
5
OUT1-
TX1
Channel 1
2
4
OUT1+
1
2
IN1+
RX1
6
1
IN1-
9
5
OUT2-
TX2
Channel 2
4
4
OUT2+
3
2
IN2+
RX2
8
1
IN2-
