13.8AIStargetsymbols
Yourmultifunctiondisplayshowsarangeofsymbolstorepresent
thedifferenttypesofAIStarget.
TargettypeDescriptionSymbol
TransmittingtargetTargetismovingorat
anchor(Targetisnot
activated,dangerous
orlost).
ActivatedtargetT argetactivated—
thatis,AISvector
displayed.Vector
line(optional)shows
predicteddistance
travelledwithinagiven
time.
Selectedtarget
Targetselectedwith
cursor.Canview
detaileddata.
Dangeroustarget
Targetswithinspecied
distance(CPA)ortime
(TCPA).Dangerous
targetalarmsoundsif
enabled.Targetred
andashing.
Uncertaintarget
CalculatedCPA/TCPA
valueuncertain.
Losttarget
Whenthesignalof
adangeroustarget
notreceivedfor20
seconds.Target
inlatestpredicted
position.Alarms
soundsifenabled.
Targetashes.
BuddytargetTargethaspreviously
beenaddedtothe
BuddyList.
AidToNavigation
(AToN)target(Real)
AToNtargetisON
position.
AidToNavigation
(AToN)target(Real)
AToNtargetisOFF
position.
AidToNavigation
(AToN)target(Virtual)
AToNtargetisON
position.
AidToNavigation
(AToN)target(Virtual)
AToNtargetisOFF
position.
Landbasestation
target
Landbasestation
targetisONLINE.
Searchandrescue
transponders(SARTS)
target
SARTStarget
Searchandrescue
aircraft(SARS)target
SARStarget
Militaryandlaw
enforcementtarget
Onlydisplayedwhen
connectedtoapproved
STEDS-EAISAIS
hardware.
13.9DisplayingdetailedAIStarget
information
Fromthechartorradarapplication:
1.SelectanAIStarget.
TheAIStargetcontextmenuisdisplayed.
2.SelectViewFullAISData.
AISData
ThetablebelowshowstheAIStargetinformationwhichif
availablewillbedisplayedonthemultifunctiondisplay:
•Type
•Status
•Destination
•LastSeen
•ETA
•MMSI
•CallSign
•IMONo.
•Length
•Beam
•Draught
•Heading
•ROT
•Position
•COG
•SOG
•CPA
•TCPA
Note:Availabledataisdependantuponwhatinformationis
beingtransmittedfromthetargetvesselandthetypeofAIS
unitconnectedtoyoursystem.
