4.5Networkconnections
YoucanconnectanumberofdigitaldevicestoyourmultifunctiondisplayusingtheNetworkconnector(s)attherearoftheunit.
Atypicalnetworkofdigitaldevicesmayinclude:
•Upto6Raymarinemultifunctiondisplays.
•SeaT alk
hs
orRayNetdigitaldevicessuchasasonarmoduleandradarscanner.
•EthernetIPcameras.
Note:Yourmultifunctiondisplayincludesthefollowingnetworkconnectors:
•e7,e7D,a65anda67=1xSeaTalk
hs
/RayNetconnector.
•NewcSeriesandNeweSeries(excludingthee7ande7D)=2xSeaT alk
hs
/RayNetconnectors.
NetworksrequiringadditionalnetworkconnectionswillrequireaRaymarinenetworkswitch.
TypicalSeaTalk
hs
network
D12 25 1-1
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
3 4221
1.Raymarinenetworkswitch.
2.Multifunctiondisplay.
3.Raymarineradarscanner.
4.Thermalcamera.
Note:NewaSeriesdisplaysdonotsupportconnectiontoathermalcamera.
Networkhardware
ItemPartnumberNotes
HS5SeaT alk
hs
network
switch
A80007
5–portswitchfor
networkconnection
ofmultipleSeaTalk
hs
devicesfeaturing
RayNetconnectors.
Equipmentwith
SeaTalk
hs
connectors
canalsobeconnected
viasuitableadaptor
cables.
SeaTalk
hs
network
switch
E55058
8–portswitchfor
networkconnection
ofmultipleSeaTalk
hs
devices.
ItemPartnumberNotes
SeaTalk
hs
crossover
coupler
E55060Enablesdirect
connectionof
SeaTalk
hs
devices
tosmallersystems
whereaswitchis
notrequired.Also
enablestheconnection
ofSeaTalk
hs
devices
toanHS5SeaTalk
hs
networkswitch(in
conjunctionwitha
RayNettoRJ45cable).
EthernetCoupler
R32142Enablesdirect
connectionofethernet
orSeaTalk
hs
devices
tosmallersystems
whereaswitchisnot
required.Alsoenables
theconnectionof
ethernetorSeaT alk
hs
devicestoanHS5
SeaTalk
hs
network
switch(inconjunction
withaRayNettoRJ45
cable).
Cablesandconnections43
