13.
1Technicalspecification—Basestation
ThefollowingtechnicalspecificationapplytotheRay90andRay91.
Powerspecification
Nominalsupplyvoltage
12Vdc(withovervoltageprotection)
Operatingvoltagerange10
.2Vdcto16Vdc
Fuserequirements
•Inlinefuse=10A
•Thermalbreak
er=7A
Currentconsumption
•L essthan6Aathighpower(13.6V)
•Standby:600mA
•Receive:2A
•Loudhailer:3A(8Ω)/6A(4Ω)
LEN1
Environmentalspecification
Operatingtemperature
-25ºC(-13ºF)to+55ºC(131ºF)
S toragetemperature
-25ºC(-13ºF)to+70ºC(158ºF)
R elativehumidity
95%
W aterproofingIPx6&IPx7
Connections
Wiredhandsets
x2viaHS1andHS2connectors
Wirelesshubx1viaHubconnector
GNSS(GPS)antennax1viaGPSconnector(TNC)(
VHFantenna/splitterx1viaVHFconnector(50OhmSO239)
NMEA0183input
x1viabareendedwiresondatacable
NMEA0183output
x1viabareendedwiresondatacable
NMEA2000/Sea Talkng®x1viaN2K(DeviceNet)connector
L oudhailerx1viabareendedwiresondatacable.
VHFT ransmitter
ChannelsAllavailableUS,InternationalandCanadianVHFmarine
bands
FrequencyR ange
156.025MHzto157.425MHz/155.500MHzto161.425
MHz(Privatechannels)
Frequencystability
+/-1.5ppm
ChannelSpacing12.5kHz
P owerOutput
•Lowpowersetting—1W
•Highpowersetting—25W
Spuriousemissions
Betterthan–36dBmat25W(L essthan0.25µW)
Maximumdeviation
+/-5KHz
Antennaimpedance
50Ohms(typical)
R eceiver
R eceivertypeDoubleconversionsuperheterodyne
ChannelsAllavailableUS,InternationalandCanadianVHFmarine
bands
136
