11Wirelesshandsetchargingholster–powerconnection

Toenableinductivechargingofthewirelesshandset,theholsterrequiresa12Vdcpowersupply.

Thepowercablesshouldbeconnectedviaadistributionpanelor,ifrequireddirectlytoabattery.

R efertothePowerdistributionsectionforguidanceonconnectingtoapowersupply.

In-linefuseandthermalbreakerratings

Thewirelessspeakerisinternallyfused,howeveritisrecommendedthatyouﬁtaninlinefuseonthe

positivewireofyourproduct’spowercableorconnectusingathermalbreaker.

In-linefuseratingThermalbreak errating

2A(refertonotebelow)

Note:

•Thesuitablefuseratingforthethermalbreak erisdependentonthenumberofdevicesyouare

connecting.IfindoubtconsultanauthorizedRaymarine

dealer.

4. 12Wirelesshandsetconnections

TheWirelesshandsetconnectswirelesslytotheWirelesshub,andtheWirelessspeakerconnects

wirelesslytotheWirelesshandset.

default chapter5
