Raymarine RAY91 VHF User Manual

1.Y ellow=Receivepositive(+)wire
2.Green=Receivenegative(-)wire
3.White=Transmitpositive(+)wire
4.Brown=Transmitnegative(-)wire
TheNMEAwiresshouldbeconnectedtoacompatibledeviceasshowninthetablebelow:
NMEA0183wiresNMEA0183device
R eceivepositive(+)
to
Transmitpositive(+)
R eceivenegative(-)
to
Transmitnegative(-)
T ransmitpositive(+)
to
Receivepositive(+)
T ransmitnegative(-)
to
Receivenegative(-)
4.8L oudhailerconnection
ALoudhailer(M95435)canbeconnectedtotheradiousingtheloudhailerwires.
Cablesandconnections57

Raymarine RAY91 VHF Specifications

General

Brand	Raymarine
Model	RAY91 VHF
Category	Radio
Language	English
