•Select Set-up
Proceduresfornavigatingmenuhierarchies.
Menuhierarchiesareusedinthisdocumenttoprovideaquicksummaryonhowtoaccessa
particularfunctionormenuoption.
Examples:
•TheinternalsonarmoduleisturnedofffromtheFishfinderapplicationmenu:
Menu>Set-up>
SounderSet-up>InternalSounder.
•TheinternalGPScanbeswitchedofffromtheSet-upmenu:
Menu>Set-up>GPSSet-up
>InternalGPS.
Documentillustrations
Y
ourproductandifapplicable,itsuserinterfacemaydifferslightlyfromthatshownintheillustrations
inthisdocument,dependingonproductvariantanddateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
2.2Productoverview
TheRay90andRay91are12Vdc,ClassDDigitalSelectiveCalling(DSC)VHFradios.DSCenables
youtomakeandreceivecallstoaspecificradio,andtotransmitandreceivepositioninformationto
andfromaselectedradio.DSCalsoallowstransmissionofadistressalert,toallradioswithinrange,
atthetouchofabutton.OnceaDSCrequestissentandacknowledgedvoicecommunicationis
carriedoutonthechannelchosenbythecaller.Theradiocantransmitandreceiveonallavailable
US,Canadian,InternationalandPrivatemarineVHFchannels.
TheRay90includesthefollowingfeatures:
•Built-inGNSS(GPS)receiverrequiringanexternalantenna.
•Upto2fullyfunctioningwiredhandsetstationswithwiredspeakerconnections.
•Connecttoawirelesshubtoaddupto3fullyfunctioningwirelesshandsetstationswithwireless
speakerconnections.
•Withanoptionalloudhailerconnectedtheradiocanalsobeusedasafoghornorloudpublic
address(PA)system.
TheRay91includesthesamefeaturesastheRay90andalsohasabuilt-inAISreceiver.
2.3Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
NameP artnumber
R ay90E70492•Suppliedwithawiredhandsetand
speaker.
R ay91E70493•Includesbuilt-inAISreceiver.
•Suppliedwithawiredhandsetand
speaker.
R equiredadditionalcomponents
Y ourproductrequiresaVHFantennatofunctionasaradio.Ifyouintendtousetheradio’sinternal
GNSS(GPS)receiverthenyouwillalsorequireaGNSS(GPS)passiveantennatobeconnected.
P artnumberDescription
N/A
3
rd
P arty50ohmVHFantenna
A 80288
PassiveGNSS(GPS)antenna
Documentandproductinformation
19
