6.2Connectingawirelesshandsettothehub

WirelesshandsetsmustbeconnectedtotheradioviaaWirelesshub

WhentheWirelesshandsetispoweredonfortheﬁrsttimeyouwillneedtoconnectittoaWireless

hub.

1.Select Wirelesshub.

Thehandsetwilldisplayalistofwirelessdevicesinrange.

2.SelectyourWirelesshubfromthelist.

TheWirelesshub’sdefaultnameis‘RM’followedbythe6digitpartnumberand7digitserial

numberoftheradiothattheWirelesshubisconnectedto(e.g.:Radiopartnumber:E70625and

serialnumber:1070828=Hubname:RME70625107828).

3.Enterthepassword.

Y oucanchecktheWirelesshub’spasswordusingaWiredhandsetbyselecting: Menu>Set-up>

Wirelessset-up>Wirelesshubset-up>Password.

ThehandsetwillnowconnecttotheWirelesshub.

4.Select

OK.

Wirelesshandsetstations85
