ConnectionConnectstoSuitablecables
1
GNSS(GPS)antenna
connection
P
assiveGNSSantennaGNSSantenna’sfittedcable.
2
Earthstud
DONO
TCONNECT
N/A
3
VHFantennaconnection
VHFantennaorSplitterVHFantenna
’sfittedcable.
4P
oweranddataconnection
•12Vdcpowersupply
•NMEA0183devices
•LoudHailer
•Suitablepowerextension
orcircuitbreaker.
•cablesuppliedwithyour
NMEA0183device
•Loudhailer’sfittedcable
5
HS1(Handsetstation1)
connection
WiredhandsetorAdaptor
cable
Wiredhandset’ sfittedcable.
6
HS2(Handsetstation2)
connection
WiredhandsetorAdaptor
cable
Wiredhandset’
sfittedcable.
7HubconnectionWirelesshubconnection
Wirelesshub ’sfittedcable.
8
N2K(NMEA2000)
connection
Sea Talkng®/NMEA2000
backbone
ThesuppliedDeviceNetto
SeaTalkng®adaptorora
DeviceNetspurcable.
4.3P owerconnection
Thepowersupplyshouldbeconnectedasshownbelow:
1.R adio’sfittedpowercable.
2.In-linefuse.
3.Powersupplypositive(+)Redwire
4.12Vdcpowersource(i.e.:Distributionpanel).
5.Powersupplynegative(-)Blackwire.
6.Suitablewaterproofconnection(Radioissuppliedwithbulletcrimpsonpowersupplywires.)
7.If,requiredyoucanextendthepowercablesuppliedwithyourradio,usingsuitablyratedcabling.
Warning:12Voltdconly
Thisproductmustonlybeconnectedtoa12voltdcpowersource.
50
