SeaTalk Service Manual 4
4. Product History (Z080 Masthead Transducer)
Change Serial No. Comments
Production Start 590001
Drain hole added to anemometer
boss K90001
Connector housing length
increased
K90164
A
llows mast arm assembly to be
located tighter onto mast socket
Self cut grub screws replace brass
inserts in vane and anemometer
bosses
L90000
T
ighter location of vane and cups
onto respective transducer shafts
5. Spares Numbers (Z080 Masthead Transducer)
Item Catalogue No. Comments
Vane transducer pod Q001
U
sed on both Z080 and Z087
transducers
Anemometer transducer pod Q002
Masthead transducer arm Q025
M
ast arm and pod housing
without transducer pods
Masthead socket and cable Q026
Vane and Cups D139
