SeaTalk Service Manual
5
Response
• Response Level Adjustment (see Operating Hints)
Response Level
Push to increase ( ▲ ) or
decrease ( ▼ ) response
level. To display response
level without changing it
push both Response keys
together briefly.
• Rudder Gain Adjustment (see Operating Hints)
Rudder Gain Level
Push and hold down for 1
second both Response keys
together to display rudder
gain level.
Rudder Gain Level
Within 10 seconds push
once to increase ( ▲ ) or
decrease (▼) rudder gain.
(Response and Rudder levels are displayed for 10 seconds only)
Illumination
Illumination Level
Push and hold down Display
for 1 second to switch on
illumination.
Within 10 seconds push
Display to select illumination
level.
3 =High
2 =Medium
1 =Low
OFF =Off
(Illumination level is displayed for 10 seconds only)
