Raymarine ST70+ User Manual

68 ST70+ User Reference Manual
Pilot Controller (power boat) keypad
Pilot Controller (sail boat) keypad
Dimensions (overall) 3.62 in (92 mm) x 5.35 in (136 mm) x 2.24 in (57 mm)
Buttons
Power ( )
STANDBY
MENU
CANCEL
Select Display ( )
AUTO
DODGE
TRACK
Rotary Control Rotate to select/adjust
Press in to perform OK function
Dimensions (overall) 3.62 in (92 mm) x 5.35 in (136 mm) x 1.63 in (41.5 mm)
Buttons
Power ( )
STANDBY
MENU
CANCEL
-1
-10
OK
Select Display ( )
AUTO
DODGE
TRACK
+1
+10
85024_1.book Page 68 Tuesday, January 27, 2009 11:31 AM

Raymarine ST70+ Specifications

General

Display Type	LCD
Waterproof	Yes
Waterproof Rating	IPX6
Interface	NMEA 2000
Power Supply	12V DC
Backlighting	Yes
Network	NMEA 2000
Input Voltage	10-32V DC
Dimensions	110mm
