Ricoh P800 User Manual

6. Optional interface board slot
Optional interface boards can be inserted.
Insert an optional wireless LAN interface board, IEEE 1284 interface board, or Device server.
Interior: Front View
EBS244
1
1. Print cartridge
Messages appear on the screen when the print cartridge needs to be replaced, or a new cartridge needs to
be prepared.
page 96 "Replacing the Toner"
Guide to Names and Functions of Components
13

Ricoh P800 Specifications

General

Print Technology	Laser
Resolution	1200 x 1200 dpi
Processor	1.3 GHz
Connectivity	Ethernet 10Base-T/100Base-TX/1000Base-T, USB 2.0
Duplex Printing	Yes
Memory	2 GB
Supported Operating Systems	Windows, macOS, Linux
Paper Capacity	Standard: 650 sheets, Maximum: 2, 300 sheets
