Ricoh P800 User Manual

Installing the IEEE 1284 Interface Board
• Before beginning work, ground yourself by touching something metal to discharge any static
electricity. Static electricity can damage the interface units.
• Do not subject the IEEE 1284 interface board to physical shocks.
1. Check the contents of the package.
2. Turn the machine off and unplug the power cord.
3. Loosen the two screws and remove the slot cover.
EBS148
The removed cover will not be reused.
4. Fully insert the IEEE 1284 interface board.
EBS153
Check that the IEEE 1284 interface board is firmly connected to the controller board.
Installing the IEEE 1284 Interface Board
23

Ricoh P800 Specifications

General

Print Technology	Laser
Resolution	1200 x 1200 dpi
Processor	1.3 GHz
Connectivity	Ethernet 10Base-T/100Base-TX/1000Base-T, USB 2.0
Duplex Printing	Yes
Memory	2 GB
Supported Operating Systems	Windows, macOS, Linux
Paper Capacity	Standard: 650 sheets, Maximum: 2, 300 sheets
