Guide to Functions of the Attention Light
• Do not push or pull the attention light when it is installed to the machine. Doing so may result in
damage or malfunction of the attention light or the machine.
The attention light notifies the user by light when there is a media jam or no media is left.
The colors of the lamp and their meanings are as follows:
Lamp Status
The bottom lamp lights blue. Printing
The bottom lamp flashes blue. Data in
The top lamp lights red. Error occurred
(Example)
• When the service call message appears
• Media jam
• Out of media
• Out of ink
Read the message on the display panel, and then
take appropriate action. For details, see
page 210 "When Messages Appear",
page 227 "Clearing Misfeeds".
Guide to Names and Functions of Components
21
