cobas c 111
Host Interface Manual
Version
2
.1
53 / 93
7.2.2.10 Photometric Calibration Result Record (M.CR)
Record used to transfer results of cobas c 111 instrument photometric calibration
measurement.
2M|1|CR^BM^c111^1|211^Ap211|Rea1.1|mmol/l|BS^Rea1||N^R|2|2005122108345
9|A^$SYS$||1.650000E-01^-3.909952E-
05|SD^^^St1.1|2110^0.0825^0.055^0.11^0^0\0^0.165^0.11 ^0.22^0^0{RT}
Field Name Reference Format
Comments (Data Content) M.CR
Record Type ID M.CR.01 ST ‘M’
Sequence Number M.CR.02 NM This record appears as the next layer of the Message Header Record. For
one record, the field value is ‘1’; for specifying several, sequence numbers
starting from 1 are assigned.
Record type sub-ID
^BMtag
^Instrument
^Version#
M.CR.03 CM CR^BM^c111^1
Roche specific record identifier
test number M.CR.04 CM Application Code (ACN - as given in masterset)
cobas c 111 instrument transmits data:
ACN^ShortName (5 chars)
test lot numb. M.CR.05 ST Reagent lot no. ISE: Electrode lot no.
Units M.CR.06 ST Example: mg/dL Indicates units of the analytical data.
Format: <UnitString > StdUnits
Test Container
Description
M.CR.07 CM Format: |BS^GLUC^1|
cobas c 111 instrument transmits data: only one field for a bottle set
carrier type => “BS” (indicates a Bottle Set)
^ShortName
^ExpirationFlag (1 = 'Expired Bottleset ', otherwise empty)
ISE: carrier type => “EL” (indicates an Electrode) Example Page 55
Test Package Number M.CR.08 CM
repeat
Format: |313^R1^1234567\313^SR^2345678|
cobas c 111 instrument transmits data: only one field for a bottle set
BCN (Bottle Code Number)
^BottleTypeText
^SerialNbr (7 digits) - repeat field for all bottles
ISE: BCN is empty, BottleTypeText is “NA”, “K”, “CL” or “REF”,
SerialNbr is the electrode serial number.
Example Page 55
Calibration method
N^M,
N^R,
M.CR.09 CM N - quantitative
L - qualitative (not currently supported by cobas c 111
instrument)
I - ISE calibration mode
M - master (Lot Master Calibration)
R - recalibration (Bottle set Calibration)
Replication number M.CR.10 Number of Replicates actually done i.e. 1 or 2
If option "Use Old" is used, calibrations are copies of an old calibration
results and do not have an order result. Therefore such calibrations do not
have replicates and the number of replicates is 0.
(See Operator manual v 2.0 page B-58)
date/time calibration
completed
M.CR.11 TS date/time when result is ready
