7.2.2.11 Photometric Absorbance Data Record (M.RR)
Record used to transfer raw absorbance data of photometric tests.
Only the analyzer can send this record.
For transfer of raw results (more values - array - for one measurement); this record is sent
in addition to the Result Record depending on the configuration settings (see Instrument
Configuration record)
M|5|RR^BM^c111^1|10|10\0\87\109\131\153\200\225\250\275\300\325\350\37
5\400\425\450\475\500\525\550\575\600\625\650\675\700\725\750\775\800\
825\850\875\900\925\950\975\1000\1025|0.055000{RT}
Field Name Reference Format
Comments (Data Content) M.RR
Record Type ID M.RR.01 ST ‘M’
Sequence number M.RR.02 NM The field value is ‘1’ for one record. To specify several records, sequence
numbers starting from 1 are assigned.
Record type sub-ID
^BMtag
^Instrument
^Version#
M.RR.03 CM Roche specific record identifier
RR^BM^c111^1
Starting value M.RR.04 NM cobas c 111 instrument transmits data:
Empty cuvette signal. For bi-chromatic measurements: the difference
between the main wavelength and sub-wavelength absorbance data of the
system calibration (‘water and air control)
Only one point is reported
A measuring point in [Abs] is multiplied with 10000 to be transmitted.
i.e. 1.2 Abs 12000 transmitted
Value list M.RR.05 NM
repeat
Repeat field.
cobas c 111 instrument transmits data:
AN
CUV
(Lm, Lr, n) or mono AN
CUV
(Lm,n) [uAbs]
For bi-chromatic measurements: the difference between the difference
between the main wavelength and the sub-wavelength absorbance data
All measured points are reported.
A measuring point in [Abs] is multiplied with 10000 to be transmitted.
i.e. 1.2 Abs 12000 transmitted
Effective signal M.RR.06 NM effective signal (only one value per single measurement)
The signal is sent in dAbs or dAbs/Min (depends on reaction model)
EndOfRecord
