CO-Series Service Manual
23
CO-200-993-S KEYP
AD ONL
Y
Interior
12
14
14
14
14
14
32
28
28
6
2
2
28
32
32
Number
Description
Pa
r
t
Number
2*
Cov
er
Cov
er
COM200C
Screw
, Cov
er
6
Baseplate Assembly
, 993
23599251
12
Batteries, AA
F206-488
14*
4AA Battery Holder
& Cov
er Kit
4AA Battery Holder
4B-E
4AA Battery Strap
Screws
, Batter
y Strap (2)
4AA Battery Cover
Screw
, Batter
y Co
ver (1)
28*
Escutcheon, 993
Escutcheon
46929279
Screws
, Escutcheon
32
Baseplate Spacer
,
993-S
Spacer
46929238
Screws
, Spacer
*
Must specify Finish
24
26
