CO-Series Service Manual
2
INTRODUCTION
This manual contains a complete listing of available parts and assemblies for CO-Series cylindrical, mortise, and exit
trim locks manufactured by Schlage Lock Company. This edition lists components of CO-Series locks manufactured after
November 2010.
Exploded views of each lock function and trim assembly are provided with accompanying charts to identify parts for
replacement purposes. Exploded views of trim are shown with parts for standard size doors. In addition, this manual
provides lock trim, ordering procedures, and all auxiliary components of the CO-Series cylindrical, mortise, and exit trim
locks.
STANDARD FEATURES
Certifications
ANSI/BHMA A156.25 Grade 1, UL 294, UL 10 C, FCC Part 15, ADA
Credential
Verification Time
Less than 1 second
Visual/Audible
Communications
Tri-colored LEDs and audible indicators
Max Current
Requirement
Up to 250 mA
Operating
Humidity
0-100% condensing
Operating
Temperature-
Exterior
-31° to 151°F (-35° to 66°C)
Operating
Temperature-
Interior
32° to 120° (0° to 49°C) (battery)
System Interface
CO-200/250: Handheld Device
Power Supply
4 AA batteries (standard off the shelf: included)
Latch Bolt
Cylindrical:
¹⁄₂" throw security latch, ³⁄₄" throw optional
Mortise:
³⁄₄" throw with anti-friction tongue standard
Voltage Range
4 VDC to 7 VDC
Reader Options
Keypad only, Magnetic Stripe Card**, and Prox Card**
Strike
Cylindrical: ANSI curved lip strike 1
¹⁄₄" x 4⁷⁄₈" x 1³⁄₁₆" lip to center standard, optional strikes, lip lengths, and
ANSI strike box available
Mortise: ANSI curved lip strike 1
¹⁄₄" x 4⁷⁄₈" x 1³⁄₁₆" lip to center with dust box standard, optional strikes lip
lengths available
Backset
Cylindrical: 2
³⁄₄" standard, 2³⁄₈", 3³⁄₄", and 5" optional
Mortise: 2
³⁄₄" only
Cylinder
Schlage 6-Pin Full Cylinder (PD), C123 keyway, keyed different (PD)
Door Range
1
³⁄₄" standard, 1³⁄₈" to 2³⁄₄" optional (available in ¹⁄₈" increments)
Keys
Two nickel silver cut keys per lock, 6-Pin, C123 section
** Available with and without keypad
