MOUNTING SCREW AND SPINDLE DETAILS FOR CY, MS, AND MD
The charts below show the details of items that vary by door thickness. These parts are not sold individually. They can be
purchased within the Door Thickness Kits which are shown on page 41.
Item
Baseplate Mounting Screws Type and
Length
Door Thickness
1³⁄₈
" 1¹⁄₂" 1⁵⁄₈" 1³⁄₄" 1⁷⁄₈" 2" 2¹⁄₈" 2¹⁄₄" 2³⁄₈" 2¹⁄₂" 2⁵⁄₈" 2³⁄₄"
A
#10-24 x
⁷⁄₈" Pan Head Phillips Machine Screw
xxxx
#10-24 x 1
¹⁄₈" Pan Head Phillips Machine Screw
xxx xx
#10-24 x 1
³⁄₈" Pan Head Phillips Machine Screw
xx
#10-24 x 1
⁵⁄₈" Pan Head Phillips Machine Screw
xx
#10-24 x 1
⁷⁄₈" Pan Head Phillips Machine Screw
x
x
Item UL Door Plate Screws Type and Length
Door Thickness
1³⁄₈" 1¹⁄₂" 1⁵⁄₈" 1³⁄₄" 1⁷⁄₈" 2" 2¹⁄₈" 2¹⁄₄" 2³⁄₈" 2¹⁄₂" 2⁵⁄₈" 2³⁄₄"
B
#8-32 x
³⁄₈" Flat Head Phillips Machine Screw
xxxxxxxxxxx
x
#8-32 x
⁷⁄₁₆" Flat Head Phillips Machine Screw
xxx
Item
Outside Baseplate Screws for UL Plate
Type and Length
Door Thickness
1³⁄₈" 1¹⁄₂" 1⁵⁄₈" 1³⁄₄" 1⁷⁄₈" 2" 2¹⁄₈" 2¹⁄₄" 2³⁄₈" 2¹⁄₂" 2⁵⁄₈" 2³⁄₄"
C
#8-32 x
1" Flat Head Phillips Machine Screw
xxxxxx
#8-32 x 1
³⁄₈" Flat Head Phillips Machine Screw
xxxxx
x
Item Spindle Assembly Type and Length
Door Thickness
1³⁄₈" 1¹⁄₂" 1⁵⁄₈" 1³⁄₄" 1⁷⁄₈" 2" 2¹⁄₈" 2¹⁄₄" 2³⁄₈" 2¹⁄₂" 2⁵⁄₈" 2³⁄₄"
F
CY Spindle Assembly 1.30" xxxxxx
CY Spindle Assembly 1.50" x x x
CY Spindle Assembly 1.70" xxx
MS/MD Assembly Spindle 1.65" xxxxxx
MS/MD Assembly Spindle 1.84" x x x
MS/MD Assembly Spindle 2.02" xxx
Item
Outside Baseplate Standoff Screws for
UL Plate Type and Length
Door Thickness
1³⁄₈" 1¹⁄₂" 1⁵⁄₈" 1³⁄₄" 1⁷⁄₈" 2" 2¹⁄₈" 2¹⁄₄" 2³⁄₈" 2¹⁄₂" 2⁵⁄₈" 2³⁄₄"
K
#10-24 x
³⁄₄" Flat Head Phillips Machine Screw
xxxxx
#10-24 x
1" Flat Head Phillips Machine Screw
xxx xx
#10-24 x
1¹⁄₄" Flat Head Phillips Machine Screw
xx
#10-24 x
1¹⁄₂" Flat Head Phillips Machine Screw
xx
#10-24 x
1³⁄₄" Flat Head Phillips Machine Screw
x
Item
Bottom Mounting Screws Type and
Length
Door Thickness
1³⁄₈" 1¹⁄₂" 1⁵⁄₈" 1³⁄₄" 1⁷⁄₈" 2" 2¹⁄₈" 2¹⁄₄" 2³⁄₈" 2¹⁄₂" 2⁵⁄₈" 2³⁄₄"
M
#10-24 x
³⁄₄" Oval Head Phillips Machine Screw
xx
#10-24 x
1" Oval Head Phillips Machine Screw
xx
#10-24 x 1
¹⁄₄" Oval Head Phillips Machine Screw
xx
#10-24 x 1
¹⁄₂" Oval Head Phillips Machine Screw
xx
#10-24 x 1
³⁄₄" Oval Head Phillips Machine Screw
xx
#10-24 x
2" Oval Head Phillips Machine Screw
x
x
Spindle for CY/MS/MD
Spindle Length
