Sega Let’s Go ISLAND! User Manual

100
PARTS LIST
Major Parts - Part Numbers
ITEM NO. PART NO. DESCRIPTION NOTE
1 LGI-3701UK STERN
2 LGI-3704UK LIFEBELT CENTRE
3 LGI-1402UK BANNER BILLBOARD
4 LGI-1401UK PIPE BILLBOARD
5 LGI-1403UK COVER BILLBOARD PIPE
6 LGI-3703UK COVER DOWNLIGHT
7 LGI-3560UK ASSY LED BKT LIFEBELT
8 LGI-1109UK SCREEN PROTECT LCD
9 LGI-1404UK VINYL BILLBOARD PIPE COVER
10 LGI-1026UK PERSPEX BASE UPLIGHTER
11 260-0024-02 BLOWER
12 LGI-1041UK BILLBOARD PERSPEX
13 LGI-1304UK PORTHOLE BUTTON BASE
14 509-6131UK BUTTON LRG ROUND
15 LGI-1013UK GRILLE BLOWER
16 LGI-1012UK FASCIA PANEL
17 220-5374-01 DOOR DFMD W/FR&LOCK C120 UNIV
18 220-5727-01B DOOR CASH SECURITY STS
19 LGI-3604UK SEAT COVER BTM
20 LGI-3654UK SEAT COVER BACK
21 LGI-2000 CONTROLLER
22 LGI-3800-AUK FLOOR PANEL
23 LGI-1080UK ASSY AC BKT
24 838-14551-02UK AC DISTRIBUTION BD
25 400-150-024-01 PSU 24VDC 150W LPS-150-24
26 839-1285R02 ROTARY SOLENOID DRIVE BD (LEFT)
27 839-1285R02 ROTARY SOLENOID DRIVE BD (RIGHT)
28 400-050-024-01 PSU 24VDC 50W LPS-50-24
29 400-5483 SW REGU EADP-130CF A DELTA
30 838-14515-A09 SOUND AMP ANALOG IN
31 837-14505 I/O CONTROL BD FOR JVS
32 260-0024-01UK FAN AC AXIAL DP200A
33 847-0001D-02 ASSY CASE WDE 1GB EXP
34 130-5156-02-91 SPEAKER BOX 8OHM 20W VA1 YL
35 838-14548-01UK SW & C VOL BD
36 200-6052-SMSNG DISPLAY 52” LCD SAMSUNG
21

Sega Let’s Go ISLAND! Specifications

General

Brand	Sega
Model	Let’s Go ISLAND!
Category	Arcade Game Machines
Language	English
