Sega Let’s Go ISLAND! User Manual

45
GAME TEST MODE
11-4 OUTPUT TEST
View the status of output devices. Use this screen to perform periodic checks on output devices.
OUTPUT TEST screen
- Press the SERVICE Button to select menu items.
-
Press the TEST Button to turn the selected item from “OFF” to “ON”. The corresponding output device should
and activate or light up. Press the TEST Button a second time when the item is “ON” to turn it to “OFF” and
deactivate or darken the device.
- Select “EXIT” and press the TEST Button to return to the GAME TEST MENU screen.
■Controls
■Menu Items
1P CONT Performs an operational check on the 1P (left seat) controller.
OFF Controller motor is inactive.
KNOCK 1P controller motor is active and repeats a knocking
motion.
MOTOR 1P controller motor is turned on and running.
1P START LAMP Normal if the 1P START button lights up when “ON” and goes dark when
“OFF”.
2P CONT Performs an operational check on the 2P (right seat) controller.
OFF Controller motor is inactive.
KNOCK 2P controller motor is active and repeats a knocking
motion.
MOTOR 2P controller motor is turned on and running.
2P START LAMP Normal if the 2P START button lights up when “ON” and goes dark when
“OFF”.
REAR LAMP Normal if the lamps on the back of the seat and in the shark’s mouth cycle
through colors as shown below when the switch unit TEST Button is pressed.
OFF → BLUE → RED → MAGENTA → GREEN → CYAN → YELLOW
→ WHITE
OUTPUT TEST
1P CONT OFF
1P START LAMP OFF
2P CONT OFF
2P START LAMP OFF
REAR LAMP OFF
> EXIT
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
11
