9.2.7 Roller-contact bearings
9.2.7.1 Uninstalling roller-contact bearings
Preparation
● Remove any grease feeders, shock pulse measurement equipment and possibly mounted
instrumentation at the DE and NDE.
● Remove the coupling on the drive end or make the shaft extension freely accessible.
● At the NDE, proceed as follows:
– First, uninstall the fan cowl or external fan cowl.
Fan cowl (Page 107)
External fan cowl
– Remove the external fan.
External fan made of metal (Page 108)
External fan made of plastic (Page 109)
Note
For a schematic diagram of the respective component layout, see the chapter "Spare parts
(Page 117)".
Procedure
1. Remove the bearing mounting components.
– Remove the outer bearing cover if one is being used.
Remove V ring (Page 111).
Removing the labyrinth sealing ring (Page 111).
– Ensure that the inner bearing cover is no longer attached to the bearing housing or end
shield.
– Support the rotor for the removal of bearing housing or end shield.
– If necessary, remove the bearing housing from the end shield.
– Remove the end shield. Depending on the shaft height, roller bearing type and design,
it is either a bearing head version or a bearing housing version.
– Remove the locking ring from the shaft.
2. Pull off the roller bearing together with the grease slinger.
Maintenance
9.2 Corrective Maintenance
SIMOTICS TN Series N-compact 1LA8
110 Operating Instructions 05/2016
