Spare parts
10
10.1 Ordering data
In addition to the exact part designation, please specify the machine type and serial number
in all orders for spare parts. Ensure that the spare part designation matches that on the spare
parts list and make sure you use the appropriate part number as well.
Example
● Bearing shield, drive end (Part 5.00)
● Machine type
● Serial number
The machine type and serial number can be found on the rating plate. The serial number is
also stamped on the end face of the shaft extension at the drive end.
Note
The graphical representations in this chapter show schematic diagrams of the basic versions.
They are used for spare parts definitions. The supplied version may differ in details from these
representations.
10.2 Using commercially available spare parts
You can use commercially available, standard components, but ensure that they have the
same construction type, dimensions, strength class etc.
10.3 Ordering spare parts via the Internet
Spare parts can be ordered online from the spare parts service "Spares on Web":
Spares on Web (
https://www.automation.siemens.com/sow).
You can use "Spares on Web" to determine the order numbers for motor spare parts quickly
and easily.
A short description of how to use "Spares on Web" is available on the Internet.
Guide for Spares on Web (http://support.automation.siemens.com/WW/news/en/25248626).
SIMOTICS TN Series N-compact 1LA8
Operating Instructions 05/2016 117
