10.14 Terminal box 1XB1621
Image 10-9 Terminal box 1XB1621 with standard cable entry
Image 10-10 Two-part cable entry
Table 10-10 Terminal box 1XB1621 spare parts
Part Description Part Description
20.00 Terminal box without cable entry comprising the following components:
20.20 Terminal box housing 21.41 Terminal supports
20.27 Mounting rail 21.61 Terminal strip for auxiliary circuit
Spare parts
10.14 Terminal box 1XB1621
SIMOTICS TN Series N-compact 1LA8
128 Operating Instructions 05/2016
