1.2 The Touch Panels at a Glance
SIMATIC TP37
SIMATIC TP27
Hardware TP27-6
Monochrome
TP27-6
Color
TP27-10
Color
TP37
Color
Models Monochrome
display
Color display
4
–
–
4
Display
Type STN
1)
-LCD TFT
2)
-LCD
Size 5.7” 10.3”
Touch screen Matrix 20 x 15 Analog, resistive
Resolution (pixels) 320 x 240 640 x 480
Colors 8
Grey shades
8
Back–lighting 4
Indicators LEDs for – TP on
Temperature limit
value reached
Write/read access to
memory card
Interfaces
Serial interface to
connection
From PLC,
PC/PU, printer
2 x RS232/TTY
(active/passive)
1 x RS422/RS485
2 x RS232/TTY
(active/passive)
1 x RS422/RS485
1 x TTY (passive) /
RS422/RS485
Parallel interface for
connecting a printer
– 1 x TTL (Centronics)
1)
passive drive
2)
active drive
