6-13
TP27, TP37 Equipment Manual
Release 01/00
6.2.2 Opening a Message Buffer
An overview of the message events which have arrived on the Touch Panel is
provided concerning the
S alarm message buffer
S event message buffer.
Open message buffers are constantly updated.
In order to open the alarm message buffer, touch
S the message indicator on the alarm message screen
or
S the OPEN ALARM MESSAGE BUFFER button on the
Edit Message standard screen
To open the event message buffer, touch the OPEN EVENT
MESSAGE
BUFFER button on the Edit Message standard screen
The message buffers in the Touch Panel list all the message events which have
occurred in chronological order. The basic structure and the significance of the
buttons do not differ from those illustrated in the example alarm message
screen in figure 6-4.
Purpose
Alarm message
buffer
Event message
buffer
Structure
Messages
