6-12
TP27, TP37 Equipment Manual
Release 01/00
ESCHELP
0000049 A 11:32:00 27.03.97 AGR:01
Boiler pressure too high: 12.7 bar
0000049 AK 11:33:20 27.03.97 AGR:01
Boiler pressure too high: 10.3 bar
0000010 A 11:34:36 27.03.97 AGR:02
Oil supply stopped
0000010 AK 11:35:18 27.03.97 AGR:02
Oil supply stopped
Message indicator
Figure 6-4 Alarm message screen (example TP37 )
Button Function Purpose
Scroll Scroll backwards/forwards one line
at a time.
Jump Scroll backwards/forwards one
screen at a time
(TP37 only).
HELP
Display Help text Call help text for the marked
message, if configured.
Toggle Toggle back and forth between
alarm message screen and alarm
message buffer.
ESC
Cancel (Escape) Close message page.
Meanings of
buttons
Messages
