Description
10 Revision 03 * INSTALLATION AND OPERATING INSTRUCTIONS 8DJH * 500-8067.9
6 Functional modules (selection)
Overview: Configurability of
panel modules
Examples for
panel modules
Panel modules Panel width Freely configurable
arrangement in panel
blocks
Stipulated arrangement
in panel blocks
R Ring-main feeder 310 mm X
T Transformer feeder with switch-disconnector/fuse combination 430 mm X
L Circuit-breaker feeder 430 mm X
K Cable feeder (combinations of transformer and circuit-breaker feeder
are possible via panel extensions)
310/430 mm X
Fig. 1: Ring-main feeder type R
Fig. 2: Transformer feeder type T
Fig. 3: Circuit-breaker feeder
type L (430 mm)
