500-8067.9 * INSTALLATION AND OPERATING INSTRUCTIONS 8DJH * Revision 03 61
Installation
Installation
11 Preparing installation
11.1 Packing
The transport units can be packed as follows:
• On pallets, covered with PE protective foil
• In a seaworthy crate (switchgear is sealed with desiccant bags in PE foil)
• Other packings in special cases (e.g. latticed crate, cardboard cover for air freight)
Transport unit On the customer’s request, transport units may consist either of:
• Individual switchpanels
or
• Panel blocks with up to four functions
and accessories
11.2 Completeness and transport damage
Checking for completeness
Ö Check whether the delivery is complete and correct using the delivery notes and
packing lists.
Ö Compare the serial numbers of the switchgear on the delivery note with those on
the packing and the rating plates.
Ö Check whether the accessories included in the subframe are complete.
Transport damages Ö Temporarily open the packing in a weatherproof place to detect hidden damages.
Do not remove the PE foil until reaching the final mounting position in order to keep
the switchgear as clean as possible.
Ö Check the switchgear for transport damages.
Ö Check the gas density (see Page 97, "Final tests after installation",
Checking the "Ready-for-service indicator“).
Ö Refit the packing as far as possible and useful.
Ö Determine and document detected defects and transport damages immediately,
e.g. on freight documents.
Ö As far as possible, document larger defects and transport damages photographically.
Ö Repair or have the transport damages repaired.
ATTENTION!
Packing and consumable materials of the switchgear must be disposed of in an
environmentally compatible way or recycled.
Ö Observe the local regulations for disposal and environmental protection.
