48 Revision 03 * INSTALLATION AND OPERATING INSTRUCTIONS 8DJH * 500-8067.9
Electromagnetic
compatibility - EMC
The a.m. standards as well as the "EMC Guideline for Switchgear"* are applied during
design, manufacture and erection of the switchgear. Installation, connection and
maintenance have to be performed in accordance with the stipulations of the operating
instructions. For operation, the legal stipulations applicable at the place of installation
have to be observed additionally. In this way, the switchgear assemblies of this type
series fulfill the basic protection requirements of the EMC guideline.
The switchgear operator / owner must keep the technical documents supplied with
the switchgear throughout the entire service life, and keep them up-to-date in case of
modifications of the switchgear.
* (Dr. Bernd Jäkel, Ansgar Müller; Medium-Voltage Systems - EMC Guideline for
Switchgear; A&D ATS SR/PTD M SP)
Protection against solid
foreign objects, electric
shock and water
The panels of 8DJH fulfill the following degrees of protection according to
IEC 62 271-200, IEC 60 529 and DIN VDE 0671-200:
• IP2X standard for parts under high voltage in switchgear panels with HV HRC fuses
• IP3X option for switchgear enclosure of operating front and side walls with
locking device
• IP65 for parts under high voltage in switchgear panels without HV HRC fuses,
or without air-insulated metering panels
Transport regulations According to "Annex 1 of the European Agreement concerning the International Carriage
of Dangerous Goods by Road (ADR) dated September 30th, 1957" Siemens gas-
insulated medium-voltage switchgear does not belong to the category of dangerous
goods regarding transportation, and is exempted from special transport regulations
according to ADR, Clause 1.1.3.1 b.
8.7 Switchgear versions - Dimensions and weights
The transport weight results from the switchgear weight per transport unit and
the packing weight. The packing weight results from the transport dimensions and
the type of transport.
Packing weights
Maximum width of
switchgear unit [mm]
Packing weight for Europe,
approx. [kg]
Packing weight for overseas,
approx. [kg]
850 30 90
1200 40 120
1550 50 150
1800 60 180
2000 75 225
