$GGUHVVLQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
8-7
&38&
The integrated inputs and outputs of this CPU have the following addresses:
Table 8-2 Integrated inputs and outputs on the CPU 313C
,QSXWV2XWSXWV 'HIDXOWDGGUHVVHV 5HPDUNV
24 digital inputs 124.0 to 126.7
of those are 12 Inputs for
technological functions:
124.0 to 125.0
125.4 to 125.6
16 digital outputs 124.0 to 125.7
of those are 3 Inputs for
technological functions:
124.0 to 124.2
4 +1 analog inputs 752 to 761
2 Analog outputs 752 to 755
All digital inputs can be programmed
as interrupt input.
Optional technological functions:
• Counting
• Frequency measurement
• Pulse width modulation
&38&3W3DQG&38&'3
The integrated inputs and outputs of these CPUs have the following addresses:
Table 8-3 Integrated inputs and outputs on the CPU 313C-2 PtP/DP
,QSXWV2XWSXWV 'HIDXOWDGGUHVVHV 5HPDUNV
16 digital inputs 124.0 to 125.7
of those are 12 Inputs for
technological functions:
124.0 to 125.0
125.4 to 125.6
16 digital outputs 124.0 to 125.7
of those are 3 Inputs for
technological functions:
124.0 to 124.2
All digital inputs can be programmed
as interrupt input.
Optional technological functions:
• Counting
• Frequency measurement
• Pulse width modulation
