&RQILJXULQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
5-38 A5E00105492-03
1HWZRUN&RPSRQHQWV
352),%86EXVFDEOH
For PROFIBUS DP or MPI networking we offer you the following bus cables for
diverse fields of application:
Table 5-18 Available bus cables
%XVFDEOH 2UGHU1R
PROFIBUS cable 6XV1 830-0AH10
PROFIBUS cable, halogen-free 6XV1 830-0CH10
PROFIBUS underground cable 6XV1 830-3AH10
PROFIBUS trailing cable 6XV1 830-3BH10
PROFIBUS cable with PUR sheath for
environments subject to chemical and
mechanical stress
6XV1 830-0DH10
PROFIBUS bus cable with PE sheath for
the food and beverages industry
6XV1 830-0BH10
PROFIBUS bus cable for festooning 6XV1 830-3CH10
3URSHUWLHVRI352),%86FDEOHV
The PROFIBUS cable is a shielded twisted-pair cable with copper conductors. It is
used for line transmission in accordance with US Standard EIA RS485.
The table below lists the characteristics of these bus cables.
Table 5-19 Characteristics of the bus cables for PROFIBUS
&KDUDFWHULVWLFVRIWKHEXVFDEOHVIRU
352),%863URSHUWLHV
9DOXHV
Impedance level approx. 135 Ω to 160 Ω (f = 3 MHz to 20 MHz)
Loop resistance ≤ 115 Ω/km
Effective capacitance 30 nF/km
Attenuation 0.9 dB/100 m (f = 200 kHz)
permitted conductor cross-sections 0.3 mm
2
to 0.5 mm
2
permitted cable diameter 8 mm ± 0.5 mm
